RHEED Vision™

Home/RHEED Vision™

RHEED Vision™

rheed-vision

rheed-vision

Fully integrated multitasking acquisition software for Windows™ XP, Windows™ 7, Windows™ 10

RHEED Image and Data Acquisition Software Comparison Chart

RHEEDVision™ RHEEDVision™ Essentials RHEEDVision™ PRO
Camera included NS1044BU NS1044BU NS1044BU
Sensor CCD 1/3″ CCD 1/3″ CCD 1/3″
Interface USB 2.0 USB 2.0 USB 2.0
Mode Digital Digital Digital
Gray scale depth 8 bit 8 bit 8 bit
Frames / s Up to 50 Up to 50 Up to 50
Live video Yes Yes Yes
Single image acquisition Yes Yes Yes
Movie acquisition on hard drive No Yes Yes
RHEED oscillations detection from life video feed Yes Yes Yes
RHEED oscillations detection from stored movie on hard drive No Yes Yes
Fast Fourier Analysis of oscillations No Yes Yes
Streak spacing measurement from life video feed No No Yes
Streak spacing measurement from stored movie on hard drive No No Yes
Pseudo 3-D diagrams No No No
Image filters Noise reduction Noise reduction Noise reduction
Image export formats BMP BMP BMP
Video export formats NA AVI AVI
Gain control Through software on camera Through software on camera Through software on camera
Shutter control Through software on camera Through software on camera Through software on camera
Integration of frames Yes Yes Yes
Averaging of frames Yes Yes Yes
